Vision Snap-In IO

Easily attached IO to the back of the Vision Enhanced V200/ V500/ V700/ V1040/ V1210 PLC / HMIs

The above Unitronics PLCs can support IO either remotely or locally using the ‘Snap-in’ expansion units below. The following IO modules can be easily attached to the back of your supported PLC/HMI without the need for extra adaptor modules.

Description

Snap-In I/O

Keep all of your IO and wiring in 1 place with the Snap-In IO options for Vision PLC/HMI units. Select from the V1210, V1040, V700, V570 or V560 PLCs which all allow for IO expansions to be added directly to the back of the PLC/HMI. Then simply select the Snap-In IO that best suits your requirements and snap it securely to the back of the PLC/HMI and your done. You have a modular solution that feels built in.

Snap in I/O

Often referred to as “Snap In Modules”, only  1 snap in module per display. Additional IO can be added using the DIN rail mounted modules (see IO+ options)
Inputs Outputs
Part No. Digital (Isolated) HSC/ Shaft Encoder Analogue Temp (MEAS) Transistor (Isolated) PWM/HSO Relay Analogue Manuals
V200-18-E1B 16 pnp/npn 2 10kHz 32-bit 3 0-10 V, 0-20mA, 4-20mA 10-bit None 4 pnp/npn 2 pnp 0.5kHz npn 50kHz 10 None PDF Link
V200-18-E2B 16 pnp/npn 2 10kHz 32-bit 2 0-10 V, 0-20mA, 4-20mA 10-bit None 4 pnp/npn 2 pnp 0.5kHz npn 50kHz 10 2 0-10 V,0-20mA,4-20mA 12-bit PDF Link
V200-18-E3XB 18 pnp/npn 2 10kHz 32-bit 4 (Isolated) Thermocouple, PT100, 0-10V, 0-20mA, 4-20mA 14-bit 2 pnp/npn 2 pnp 0.5kHz npn 50kHz 15 4 (Isolated) 0-10 V, 4-20mA 12-bit PDF Link
V200-18-E4XB 18 pnp/npn 2 10kHz 32-bit 4 (Isolated) Thermocouple, PT100, 0-10V, 0-20mA, 4-20mA 14-bit 15 pnp 2 2 pnp 0.5kHz npn 50kHz None 4 (Isolated) 0-10 V, 4-20mA 12-bit PDF Link
V200-18-E5B 18 pnp/npn 2 10kHz 32-bit 3 0-10 V,0-20mA, 4-20mA None 15 pnp 2 2 pnp 0.5kHz npn 50kHz None None PDF Link
V200-18-E6B 18 pnp/npn 2 10kHz 32-bit 2 Thermocouple, PT100, 0-10V, 0-20mA, 4-20mA 14-bit 2 pnp/npn 2 pnp 0.5kHz npn 50kHz 15 2 (Isolated) 0-10 V, 4-20mA 12-bit PDF Link
V200-18-E46B 18 pnp/npn 2 10kHz 32-bit 6 0-10 V,0-20mA,4-20mA 14-bit None 2 pnp/npn 2 pnp 0.5kHz npn 100kHz 15 2 (Isolated) 0-10 V, 4-20mA 12-bit PDF Link
V200-18-E62B 30 pnp/npn 2 50kHz 32-bit 2 0-10 V,0-20mA,4-20mA 10-bit None 28 pnp 2 2 pnp 0.5kHz npn 100kHz None None PDF Link

Technical Drawings

VisiLogic

i4 Automation Visilogic Software for Unitronics

VisiLogic is an easy to use and intuitive programming software that is included with this product.

VisiLogic is a powerful software package that allows the Vision™ series of integrated PLC & HMI to be programmed easily and quickly.  The software has a familiar intuitive feel and incorporates many advanced features such as discrete program routines, function blocks, data tables, data logging, trending and alarm handling.  All of the standard maths functions are available and complex formula can be developed without the need to have a degree in computer science!

The integrated intuitive function blocks really make the Vision™ series the powerful devices that they are.  There are many pre-set function blocks available performing a wide variety of advanced tasks as easily as dropping & dragging an icon into your program and configuring a few parameters.

Subjects such as CAN Open networking, Modbus communications, pulse trains outputs and bespoke serial communication protocols all have function blocks available to make the programmers life less difficult.  To find out more detail about the range of function blocks available visit the VisiLogic software page HERE.

You can use VisiLogic and the associated software utilities to program, control, access and download data to and from the PLC remotely and directly.

Get more information about the VisiLogic programming software HERE
