EX-RC1 CANbus interface

CANbus remote I/O is a method of expanding a PLC system using a CAN‑based communication network to connect distributed I/O modules. Unitronics systems, including Vision and UniStream PLC families, use the EX‑RC1 adapter to enable this functionality.

CANbus remote I/O allows you to place I/O modules away from the main PLC and link them over a robust, noise‑resistant CANbus network. This is ideal for applications where I/O points are spread across a machine or facility

The EX-RC1 remote expansion CANbus interface is suitable for IO expansion on all Vision and Unistream products fitted with a CANbus. This can be added to the smaller display units by using one of the following products

V100-17-CAN CANbus port (Isolated) (V130, V350, V430, V700, Samba)
V100-S-CAN CANbus port (Isolated), Extended Temperature Version

Standard on V570, V560, V1210 and V1040 and USC-P-B10 (UniStream™)

If you need support, please get in touch with us and talk to a real person, and we can advise on the best solution.

Also compatible with Unistream hardware

UAC-CB-01 CAN Unistream PLC, Com 1x CANbus (USC Controller)
UAC-CX-01 CAN UniStream CX Com 1x CANbus (US5/7/10 Controllers)

Why Use CANbus for Remote I/O?

✔ Reduces wiring complexity

Instead of long home‑run cable bundles, you route a single CANbus cable around the machine.

✔ Reliable industrial communication

CANbus is designed for electrically noisy environments, ensuring stable communication.

✔ Scalable expansion

Add more I/O nodes without redesigning the entire control system — up to 60 on one network.

✔ Flexible system architecture

Distributed I/O allows modules to be placed closer to the sensors and actuators they serve.

Typical Applications

Large machinery with multiple stations
Distributed control systems
Material handling systems
Modular manufacturing equipment
Retrofit projects needing flexible I/O expansion

In Stock (UK)

Ex VAT

Description

EX-RC1 allows for remote expansion of Unitronics products via CANbus, 12/24VDC

Programmed using Visilogic software, a simple way to add additional Inputs and Outputs to your system. Compatible with standard DIN rail-mounted Vision IO modules. Comes with full technical support and training for our customers. Contact us if you need more information.

The EX-RC1 interfaces between Unitronics Vision OPLCs and remote IO Expansion Modules distributed throughout your system. The adapter is connected to a PLC via CANbus. Each adapter may be connected to up to 8 I/O Expansion Modules. The network may comprise up to 60 nodes, including both PLCs and adapters; note that the PLC must comprise a CANbus port. Communication is via UniCAN, Unitronics’ proprietary CANbus protocol.
The EX-RC1 is run by a factory-installed application. The adapter can auto-detect digital IO Expansion Modules. If the system includes analogue modules, the application must be edited. For more information, refer to the Remote I/O topics in the VisiLogic Help system.
The EX-RC1 may either be mounted on a DIN rail or screw-mounted onto a mounting plate.
